The Grim Reaper's Engine Bay

Emissions Legal L-69 - Stage 2

Since you now have an exhaust capable of much better flow it is time to update your carb.  The Stock Q-jet is 100% perfect in rebuilt trim for any street build-up on stock engines of up to 454cid!!! Do NOT let someone try to convince you that your carb is junk, for it is a cheap and reliable carb.  If you have an 1987-88 SS then you require a different electronic carb which severely limits your selection.  The Edlebrock/Carter Units are NOT  certified Emissions Legal on the Monte Carlo SS, and Holley stopped making thier version (#80073) a while ago.   Getting a quality performance rebuild on your stock carb is probably your best bet.  For HOT 305's use the CV Rods and the N Hangers, 350's like the AH rods, but the CV Rods will work as well.  The EdleBrock/Carter carbs run about $450, a Holley runs about $250 but loses MPG to gain a little performance advantage, while a performance rebuild on the Q-jet will run around $200.  You make the call.


The Edlebrock Performer intake manifold is completely emissions legal, and will add roughly 20+hp to your stock engine.  Be careful about which manifold you order!  1983-1986 SS's require EDL-3701 while the 1987-88 SS's use the EDL-3706.  There are also other good choices for intakes that are Emissions Legal.  Chevy High-Performance makes an emissions legal manifold (PN#10185063) that has similarities to the Edlebrock RPM manifold which is not yet made in Emission legal form.  See your local GM dealer. Personally I like the Edlebrock on the L-69 and the Chevy Performance intake on larger engines.  But it is a matter of preference.  The Performer Sells for around $150 while the GM unit sells for around $180.
Adding a Camshaft at this time will wake up performance by as much as 25+HP! Cam selection is one of the most difficult things to do. You must match your cam to type of driving style you intend to use your engine for.  For this reason 3 similar cams are recommended.  All are the Crane Compu-cam design which will work with your ECM and keep the engine emissions legal.  The #CC2030 is a mild cam good for a daily driver and moderate performance retaining decent MPG, net roughly 15+hp.  The #CC2040 is a favorite, and works well giving a nice blend of power and drive ability, roughly 25+HP.  The CC2050 is as extreme as you can get in a cam and remain Emissions Legal, it will net  roughly 35+HP.  Cost is around $130
Next, replace the old Stamped Steel rocker arms with a roller-tip design like the Crane Cams design. (CRN-11806) which can add around 10+hp to your engine.  These rocker do not require you to switch to screw-in studs.  As an alternative, you may use the Crane Cams full-roller rockers with "tall" valve covers. Note: On 1987-1988 SS's with the Center-bolt valve covers Full-Roller rockers will hit the valve covers unless you switch to the Moroso center bolt style (MOR-68036).  The Full-roller design requires the use of screw-in studs and guides plates.  Cost is around $250
Now that we are making power and have improved engine flow, the ignition needs to be addressed.  One of the best Ignition systems is the MSD 6a ignition.  It will improve the starting, drive ability, and improve high RPM response, where the stock ignition begins to falter.  (usually above 4200 rpm)  Alternately, Accel makes a nice street system that is a direct plug-in module.  The main difference is the accel is digital, and has a built-in rev-limiter, while the MSD is analog and uses modules to control RPM in the MSD 6al unit.  Cost on the MSD is around $180 (w/ coil), and the Accel is around $185 (w/coil).
Related upgrades:

If you do not have the Posi-traction rear axles (VIN Code G80) then you will have serious traction problems at this stage of power.  The Auburn-Pro Posi-traction differential (AUB-XXXX) is a perfect replacement and comes in the 7-5/8" size* of the stock SS (85-88).  This means you may retain the stock 3.73 gears* (85-88) or you may wish to upgrade to a "street" gear if you plan on making a lot of power later on.   If you have the G80 option then you may still wish to change to this differential since it has more clutches and is stronger.  If you decide not to upgrade your differential now, you will probably need to after completing the Stage-3 level buildup.  Cost is around $335

U-Joints are something that take plenty of abuse in high-horsepower cars, and most likely your SS has the originals still.  It is a good idea to get them replaced now before something breaks and you pole-vault your car.  Whatever style you choose as a replacement it is a good idea to get u-joints that have the zerx grease fittings rather than the sealed type.  I Like the Spicer U-joints myself.

* Note: the 1983-84 SS came stock with a 7.5" differential and a 3.42 rear gears.


This Completes the STAGE 2 buildup of the 83-88 Monte Carlo SS

Using the  Rebuilt Carb, Edlebrock Intake, Crane Cam, Crane Rockers, MSD Ignition, Auburn Differential.


Go to the L69 Stage 3 buildup.
